Cylinders

  • SH-13046 [M52x2.0/BACK] Rotary Cylinder

    SH-13046 [M52x2.0/BACK] Rotary Cylinder

    Rear mounting short-body hydraulic cylinder with 46mm bore, 15mm piston stroke; 42.3kn push - 38.1kn pull in piston force; 4.0kgf/cm2 max operating pressure; 7000 max. r.p.m; 3.0 total leakage; M52 x 1.5 draw tube threading with coolant...

    $2,765.00
    Add to Cart
  • SH-15052CAD [M60x2.0/BACK] Rotary Cylinder

    SH-15052CAD [M60x2.0/BACK] Rotary Cylinder

    Front and rear-mounting short-body hydraulic cylinder with 52mm bore, 22mm piston stroke; 60kn push - 56kn pull in piston force; 4.0kgf/cm2 max operating pressure; 6200 max. r.p.m; 3.9 total leakage; M60x2.0 draw tube threading with coolant...

    $3,350.00
    Add to Cart
  • SH-17068 Rotary Cylinder

    SH-17068 Rotary Cylinder

    Front and rear mounting short-body hydraulic cylinder with 68mm bore, 25mm piston stroke; 63kn push -59.8kn pull in piston force; 4.0kgf/cm2 max operating pressure; 5600 max. r.p.m; 4.2 total leakage; with coolant collector.    This model is...

    $3,940.00
    Choose Options
  • SH-18077 [M85x2.0/BACK] Rotary Cylinder

    SH-18077 [M85x2.0/BACK] Rotary Cylinder

    Short-body hydraulic cylinder with 77mm bore, 25mm piston stroke; 75.3kn push -69.6kn pull in piston force; 4.0kgf/cm2 max operating pressure; 5000 max. r.p.m; 4.2 total leakage; M85x2.0 draw tube threading with coolant collector   This cylinder...

    $4,140.00
    Add to Cart
  • SH-19082 [M90 x 2.0] Rotary Cylinder

    SH-19082 [M90 x 2.0] Rotary Cylinder

    Short-body hydraulic cylinder with 82mm bore, 25mm piston stroke; 78.1kn push -72.5kn pull in piston force; 4.0kgf/cm2 max operating pressure; 4800 max. r.p.m; 4.5 total leakage; M90x2.0 draw tube threading with coolant collector   See attached...

    $4,430.00
    Add to Cart
  • SH-21010  Rotary Cylinder

    SH-21010 Rotary Cylinder

    Rear-mounting short-body hydraulic cylinder with 106 mm bore; 30mm piston stroke; 91.8kn push - 87.8kn pull in piston force; , 4.0kgf/cm2 max operating pressure; 3500 max. r.p.m; 6.0 total leakage; with coolant collector   See attached drawing for...

    $5,725.00
    Choose Options
  • SH-25011 [M130 x 2.0/BACK] Rotary Cylinder

    SH-25011 [M130 x 2.0/BACK] Rotary Cylinder

    Rear-mounting short-body hydraulic cylinder with 117.5 mm bore; 23mm piston stroke; 132kn push - 121kn pull in piston force; , 4.0kgf/cm2 max operating pressure; 3000 max. r.p.m; 7.0 total leakage; M130x2.0 draw tube threading with coolant...

    $8,935.00
    Add to Cart
  • SHL-17068CAD [M75x2.0/BACK] Rotary Cylinder

    Rear-mounting,short-body, long stroke hydraulic cylinder with 68mm bore, 40mm piston stroke; 63kn push - 59.8kn pull in piston force; 4.0kgf/cm2 max operating pressure; 5600 max. r.p.m; 4.0 total leakage; M75x2.0 draw tube threading with coolant...

    $5,660.00
    Add to Cart
  • SHL-18077 (M85 x 2.0/BACK) Rotary Cylinder

    SHL-18077 (M85 x 2.0/BACK) Rotary Cylinder

    Rear mounting Short-body, long stroke hydraulic cylinder with 77mm bore, 40mm piston stroke; 75.3kn push - 69.6kn pull in piston force; 4.0kgf/cm2 max operating pressure; 5000 max. r.p.m; 4.2 total leakage; M85x2.0 draw tube threading with coolant...

    $5,910.00
    Add to Cart
  • SHL-25011 Rotary Cylinder

    SHL-25011 Rotary Cylinder

    Rear-mounting,short-body, long stroke hydraulic cylinder with 117.5mm bore, 50mm piston stroke; 32kn push - 121kn pull in piston force; 4.0kgf/cm2 max operating pressure; 3000 max. r.p.m; 7.0 total leakage; with coolant collector

    $9,830.00
    Choose Options
  • SHL-39024 (M250x3.0) Rotary Cylinder

    SHL-39024 (M250x3.0) Rotary Cylinder

    Short-body, long stroke hydraulic cylinder with 240mm bore, 51mm piston stroke; 152.5kn push - 138.7kn pull in piston force; 2.5kgf/cm2 max operating pressure; 1500 max. r.p.m; 22 total leakage; M250x3.0 draw tube threading with coolant collector

    $27,980.00
    Add to Cart
  • SYH-1036 (M42x1.5)

    Hydraulic cylinder with 36mm bore, 15mm piston stroke; 25kn push - 24kn pull in piston force; 4.0kgf/cm2 max operating pressure; 8000 max. r.p.m; 3.0 total leakage; M42x1.5 draw tube threading with coolant collector

    $2,460.00
    Add to Cart
