Samchully Soft Jaws – For 6" Power Chucks (SET OF 3)

SB06B1

Price $75.25
Write a Review
SKU:
SB06B1
Shipping:
Calculated at Checkout
Includes:
3 Jaws
Chuck Compatibility:
HS-06V1, HC-06, MH-206V1, and Kitagawa B-206
Height Options:
32mm, 40mm, 60mm, 80mm, 100mm, 120mm
Length:
72mm (2.8")
Width:
31mm (1.2")
Serration Pitch:
1.5x60
Material:
S45C Steel
Size:
6"
Adding to cart… The item has been added

Samchully Soft Jaws – For 6" Power Chucks (SET OF 3)

*For Samchully Chucks, use with M8 x 1.25 pitch socket head cap screws, 20mm thread length

Application:

These soft jaws are designed for use with the 6" Power Chuck models. Ideal for custom-machined clamping surfaces, they offer the flexibility needed for holding irregular or delicate workpieces without causing damage—perfect for high-precision turning operations where part integrity and repeatability are essential.

Product Features:

Crafted from high-quality S45C steel, these soft jaws provide excellent machinability and durability for repeated jaw boring. The jaws feature a standard 1.5mm x 60° serration pattern, ensuring a secure and accurate fit with the chuck body. Engineered to support strong clamping force while maintaining concentricity, they are the reliable choice for custom workholding in demanding machining environments.

Chuck Compatible: HS-06, HC-06, HCH-06, MH-206, JB-H306, JB-M306, & Kitagawa™ B-206

!
