HCT-12 [M20x2.5]

HCT-12 [M20x2.5]

Price $5,060.00
Write a Review
SKU:
HCT-12 [M20x2.5]
Shipping:
Calculated at Checkout
Includes:
Mounting Bolts; Soft Top Jaws; Master Jaws; T-Nuts; Handle
Kitagawa Equivalent:
NT-12
Grip Dia. Max (mm):
310
Grip Dia. Min. (mm):
22
Jaw Stroke Dia. (mm):
10.5
Plunger Stroke (mm):
30
Max. Permissible Input Force [kN(kgf)]:
27.5(2804)
Max. Static Gripping Force [kN(kgf)]:
104(10605)
Max. r.pm.:
3000
Weight [kg]:
55
Series:
HCT
Size:
12"
Jaws:
2
Includes:
2 Jaws

Back Ordered - Chat with an agent for updated lead time.

12" HCT Series Power Chuck – 2-Jaw, Closed-Center Power Chuck

Application:

The HCT-12 is a specialized 2-jaw closed-center power chuck engineered for precise clamping of irregular, non-cylindrical, or thin-walled workpieces—especially square, rectangular, or asymmetric parts. The closed-center design minimizes internal contamination, making it ideal for clean machining environments such as vertical lathes and milling-turn centers.

Technical Features:

The HCT-10 features a rigid, closed-center body that protects internal components from chips and coolant, ensuring consistent clamping force and longer service life. Its 2-jaw configuration enables gripping of square or odd-shaped parts with precision and stability. The chuck offers a jaw stroke of 10.5mm, a maximum gripping force of 104kN, and supports speeds up to 3,000 RPM. Designed for smooth, high-speed operation, the chuck body is manufactured from durable alloy steel and balanced to reduce vibration. The HCT-10 supports integration with standard hydraulic cylinders, offering a reliable solution for specialty turning applications that demand both power and part geometry flexibility.

!
