POL | Outside Pin Arbor Chuck
POL
Outside Pin Arbor Chuck
The Samchully POL Outside Pin Arbor Chuck is designed for second-operation O.D. gripping, delivering exceptional precision and stability. Its active pull-down mechanism ensures accurate workpiece positioning, while counter centrifugal gripping minimizes distortion during high-speed machining. Engineered for consistent clamping performance, the POL Series is ideal for applications requiring superior concentricity and repeatability.
TECHNICAL FEATURES
Active pull-down mechanism ensures superior accuracy by firmly seating the workpiece against the locating surface.
Counter centrifugal gripping design minimizes part distortion and maintains clamping stability at high speeds.
Optimized for second-operation O.D. clamping, providing exceptional concentricity and repeatability.
Supports maximum gripping ranges from 80 mm to 300 mm, offering versatility across a wide variety of part sizes.
