DIMENSIONS
| Model | Fig. | Spindle Nose | A | B | C | G | H | J | K | Corresponding |
|---|---|---|---|---|---|---|---|---|---|---|
| AP06A05-15T | 1 | A2-5 | 140 | 15 | 82.563 | 104.78 | 12 | 116 | 6.6 | HS/HSL/HCH/HC/HCL-06, MH-206, JBH/JBM-306 |
| AP06A05-20T | 1 | A2-5 | 140 | 20 | 82.563 | 104.78 | 12 | 116 | 6.6 | HS/HSL/HCH/HC/HCL-06, MH-206, JBH/JBM-306 |
| AP06A06-33T | 3 | A2-6 | 140 | 33 | 106.78 | 133.35 | 14 | 104.78 | M10 | HS/HSL/HCH/HC/HCL-06, MH-206, JBH/JBM-306 |
